Deck wash pump and bilge pump for commercial shipping, large pleasure craft and coastal shipping, also suitable for irrigation, irrigation, drainage and as a coolant pump for industry.
Pump type: Dry installation: self-priming
Protection class: IP68
ATEX: Yes / No
Voltage: 230V / 400V
Voltage: Alternating voltage
Frequency: 50 Hz
Suction height: 7.0 m
Press pipe diameter: 2″
Suction pipe diameter: 2″
Medium: Water
Grain size: 14 mm
Max. delivery head: 19.0 m
Fuel: –
Float switch: –
Free range (L/hr): 27000
Capacity 5 meters (L/hour): 27000
At 10 meters: 25,200 liters per hour
At 15 meters: 15,900 liters per hour
Type: 02RA-M
Color: Blue
Type of pump: self-priming centrifugal pump (1″ model limited self-priming +/- 2 meters)
Impeller type: open impeller
Type of motor: induction motor at 230 volts
Fuse: only built-in thermal protection on the 230 volt motors
Shaft seal: mechanical seal of ceramic on carbon with elastomers of neoprene or Viton (for gas oil)
Impeller material: cast iron
Pump housing material: cast iron
Pump shaft material: stainless steel AISI 420
Liquids: contaminated water, seawater, etc. maximum temperature 90°C
Insulation class: IP55
Connections: 2″ female thread
Dimensions: 474 x 205 x 321 mm
Weight: 28 kg
Amperage 230V: 9.5 A / 400V: 4.5 A
Shaft power: 1.5 kW, 2 hp, 2800 rpm
