Submersible pump for clean and slightly dirty water with a Max. temperature of +40 °C. A pump that sucks away up to 2 mm and quickly starts up again after dry suction. A fully submersible centrifugal pump with a delivery head of Max. 9 meters. Suitable for many applications, inland shipping, roofers, tennis courts, ponds, basements, etc.

The pump has a dry motor with an open impeller and is equipped with built-in thermal protection. Shaft sealing by means of a double mechanical seal of ceramic carbon and lip seal separated by an oil chamber.

Pump type: Submersible pump
Press pipe diameter: 1.1/4¨
Suction pipe diameter: –
Medium: Water
Grain size: 2 mm
Head Max.: 9.0 m
Voltage: 230 V
Voltage: Alternating voltage
Frequency: 50 Hz
Protection class: IP68
ATEX: No
Float switch: No
Free range (L/hour): 9000
Capacity 5 meters (L/hour): 4800

Type: Speed Mop
Colour: white with green
Pump type: fully submersible centrifugal pump
Impeller type: open impeller
Engine type: dry engine
Fuse: built-in thermal protection
Shaft seal: double mechanical seal of ceramic carbon and lip seal, separated by oil chamber
Immersion depth: 3 meters
Impeller material: noryl
Impeller housing material: plastic
Motor housing material: plastic
Pump shaft material: Stainless steel EN 10088-3, 1.4104
Liquids: clean and slightly contaminated water, maximum temperature +40°C (maximum 3 minutes +90°C)

Pumps away up to: 2 mm
Connections: 1.1/4″ hose connection and 1.1/4″ male thread
Dimensions: diameter 152 mm, height 270 mm
Weight: 5kg
Amperage: 2.0 A
Shaft power: 0.37 kW, 0.5 hp, 2900 rpm
Cable: 10 meters neoprene H05-RN-F with earthed plug
